Obscape Wave Module
Solar powered wave measurement unit that mounts on a buoy, platform or vessel and measures wave height, period and direction in real time.
- Full wave spectrum with height, period and direction
- Mounts on buoys, platforms or vessels
- GPS position and drift alerts
- Wireless and solar powered, 3 W
- 4G cellular, satellite optional
- SD card keeps a backup copy
Prices are given in the quote we send you.
The Wave Module measures the full wave spectrum, wave height, period and direction, in a rugged solar powered housing built for harsh marine conditions. It mounts on buoys, platforms or vessels with the brackets supplied.
Data goes over cellular to the Data Portal, with GPS position and alerts for drift or faults, and satellite is optional. If the link drops the unit stores data and uploads it once the connection returns. Direction accuracy depends on how the platform it sits on moves.
- Full wave spectrum with height, period and direction
- Mounts on buoys, platforms or vessels
- GPS position and drift alerts
- Wireless and solar powered, 3 W
- 4G cellular, satellite optional
- SD card keeps a backup copy
- Dimensions
- 195 x 87 x 87 mm
- Weight
- 2 kg
- Power
- Built-in 3 W solar panel, 18650 Li-ion battery 3.7 V
- Data transfer
- 4G cellular with 2G fallback, satellite (Iridium) optional
- Data interval
- 30 min to 24 h
- Sample frequency
- 6.25 Hz
- Frequency range
- 0.05 to 1 Hz (20 to 1 s)
- Burst duration
- 30 min
- Wave data
- Significant and max wave height, periods, direction and spreading, swell, directional wave spectrum
- Data storage
- Obscape Data Portal and SD card
Source: the manufacturer's specification.
